Hello everyone!

I've been trying to create this form (picture attached) in a conceptual mass family for a few days now, but not been successfull yet. I'm starting to wonder if it is possible to do in Revit at all. I'm new to creating free form shapes and don't know what the possibilities really are.

So far I have tried making a row of plines and created a surface with points that I can stretch to different directions. But the base of the cones don't become round but irregular in shape.

Is there another way to go around with this? I really would appreciate your thoughts on this.

Kristina

Attached Images

This user is offline

kostman70

active

Joined: Sun, Aug 24, 2014
0 Posts
No Rating

I edited the skech, also the "slab" should be free form...

Attached Images

This user is offline

Typhoon

site moderator|||

Joined: Tue, May 22, 2007
5921 Posts

Better to create that in MAX or MAYA, just my two cents.

-----------------------------------

I Hope and I Wish to LEARN  more, and more, and more.... REVIT

This user is offline

HKicsak

active

Joined: Mon, Feb 13, 2012
2 Posts
No Rating

Or you could make it in Sketch Up pretty easily. And if its important to keep it 'smart' check out this blog post: http://cadzulu.wordpress.com/2014/08/21/sketchup-to-revit-and-keeping-the-smarts/

-----------------------------------

Using Revit2014, dragging the rest of the company with me from AutoCAD2008. When will the whining stop?

This user is offline

kostman70

active

Joined: Sun, Aug 24, 2014
0 Posts
No Rating

Okay, thanks for the tips!
